STANDARD: SAE J517 TYPE 100 R12
TUBE: oil resistant synthetic rubber
REINFORCEMENT: four spiral high strength stainless steel wire
COVER: oil, abrarion & weather resistant synthetic rubber
TEMPERATURE RANGE: -40℃ /+100℃ ; -40 °F/+212°F LT-55 & HT150℃ customizable
APPLICATION: suitable for high temperature and medium pressure hoses under harsh conditions, machine tools and agricultural applications, construction machinery, oil drilling, mining machinery, steel, chemical industry, energy, rail transit, food processing and shipbuilding

Compare


Productnumber	DN	Hose I.D		W.D	O.D	W.P		B.P		minB.R	Weight	unit length
		inch	mm	mm	mm	MPa	psi	MPa	psi	mm	kg/m	metres	adaptor
GR12-06-10	10	3/8"	9.5	17.2	20.3	28	4060	112	16240	125	0.62	20/40/50	M18*1.5
													G3/8
													U9/16
GR12-08-13	13	1/2"	12.7	20.7	23.8	28	4060	112	16240	180	0.85	20/40/50	M22*1.5
													G1/2
													U3/4
GR12-10-16	16	5/8"	15.9	24.6	27.7	28	4060	112	16240	200	1.29	20/40/50	M27*1.5
													G5/8
													U7/8
GR12-12-19	19	3/4"	19	27.7	30.7	28	4060	112	16240	240	1.47	20/40/50	M30*1.5
													G3/4
													U11/16
GR12-16-25	25	1"	25.4	34.9	38.1	28	4060	112	16240	300	2	20/40/50	M39*2
													G1"
													U1"5/16
GR12-20-32	32	1"1/4	31.8	43.9	47.1	21	3045	84	12180	420	2.86	20/40/50	M45*2
													G1"1/4
													U1"5/8
GR12-24-38	38	1"1/2	38.1	50.4	53.5	18	2610	72	10440	500	3.24	20/40/50	M52*2
													G1"1/2
													U1"7/8
GR12-32-51	51	2"	50.8	63.7	17.2	17	2465	68	9860	630	4.8	20/40/50	M64*2
													G2"
													U2"1/2
